眾所周知，彩鋼板的承載能力好，外形美觀，板塊利用系數大，連接方式方便，符合國內模式的波距和波形。那么您知道彩鋼板墻體施工的6種方法具體是什么嗎？下面濟南彩鋼制作廠家為您講解吧。

As we all know, the color steel plate has good bearing capacity, beautiful appearance, large plate utilization coefficient, convenient connection mode, and conforms to the wave distance and waveform of the domestic model. So do you know what are the six methods of color steel plate wall construction? Now, Jinan Color Steel Manufacturer will explain it to you.

一、彩鋼板墻體的垂直布局

1、 Vertical layout of color steel plate wall

當布置垂直墻板時，應使用飄帶窗。這個隔斷可以減少洞口的結構，有助于防雨。使用單面窗時，窗戶兩側結構復雜，施工時不易漏雨。排板時選擇布局起始線，排板與開口大小相協調。墻板橫向排列時，主要解決窗戶兩側結構復雜，施工時不易漏雨的問題。排列印版時，選擇開放線。

When arranging vertical wallboards, ribbon windows shall be used. This partition can reduce the structure of the opening and help prevent rain. When single window is used, the structure on both sides of the window is complex, and it is not easy to leak rain during construction. Select the starting line of layout when arranging plates, and the plate arrangement shall be consistent with the opening size. When the wallboards are arranged horizontally, the problem that the structure on both sides of the window is complex and it is not easy to leak rain during construction is mainly solved. When arranging plates, select open lines.

二、彩鋼板設置要橫向墻體

2、 Color steel plate shall be set with horizontal wall

側墻板主要用于夾芯板，有時也用于單層異型板。這種方法將板寬作為模塊的垂直布局。設計大于板寬的孔洞時，盡量將孔洞的上下邊緣與板的橫縫結合，以免造成結構復雜。橫向墻板多與柱中軸線分開，首尾柱之間的板長為柱距尺寸，加上首尾柱的軸向長度為柱距尺寸，中間墻板的長度為柱距尺寸，柱軸線的長度為柱距尺寸。根據不同的斜坡，斜坡上石板的長度。

Side wall panels are mainly used for sandwich panels, and sometimes also for single-layer profiled panels. This method takes the board width as the vertical layout of the module. When designing holes larger than the width of the plate, try to combine the upper and lower edges of the holes with the transverse joints of the plate to avoid complex structures. The horizontal wall panel is mostly separated from the column axis. The length of the panel between the head and tail columns is the column spacing dimension, plus the axial length of the head and tail columns is the column spacing dimension, the length of the middle wall panel is the column spacing dimension, and the length of the column axis is the column spacing dimension. According to different slopes, the length of the slab on the slope.

三、彩鋼板墻體無絕緣板連接

3、 Color steel plate wall without insulation board connection

非絕緣板連接有兩種：明接和暗接。接合時，將接合的扣件連接到接頭上，接頭與墻梁連接。這種連接使得緊固件的頭部在墻壁的凹入部分更美觀。當某些波距較大時，連接扣件也可設置在波峰處。隱蔽板的覆蓋范圍很窄。一板與墻體連接后，二板插入一板的邊槽，抵抗負風壓。

There are two types of non insulated board connection: exposed connection and concealed connection. When jointing, connect the jointed fastener to the joint, and the joint is connected with the wall beam. This connection makes the recessed part of the fastener head in the wall more beautiful. When some wave distances are large, the connecting fasteners can also be set at the wave crest. Covering area of concealed board is very narrow. After the first plate is connected with the wall, the second plate is inserted into the side groove of the first plate to resist negative wind pressure.

四、夾板連接

4、 Splint connection

夾芯板的連接方式有工字鋼連接、承插連接和暗扣連接。

The connection methods of sandwich panels include I-beam connection, socket connection and concealed connection.

五、彩鋼墻基礎結構

5、 Color steel wall foundation structure

墻體結構主要解決防止雨水滲入室內的問題。為防止墻體留下的雨水滲入室內，接縫處的地面和矮墻頂部用混凝土澆筑成60mm高的彩鋼板混凝土框架。

The wall structure mainly solves the problem of preventing rainwater from seeping into the room. In order to prevent rainwater left by the wall from seeping into the room, the ground at the joint and the top of the low wall shall be concreted into a 60mm high color steel plate concrete frame.

六、門窗安裝

6、 Door and window installation

門窗的輪廓尺寸和洞口尺寸要緊密結合。一般門窗比洞口小5mm左右，安裝誤差太大。一般安裝在鋼墻梁上，也有安裝在墻板上的門窗。此時，根據門窗的輪廓尺寸在墻板上打孔。安裝好門窗框后，用密封膠密封門窗。在門框外安裝門窗時，應先在門窗周圍安裝包裝帶，并壓緊包裝帶。

The outline dimensions of doors and windows shall be closely combined with the opening dimensions. Generally, the doors and windows are about 5mm smaller than the opening, and the installation error is too large. Generally, it is installed on the steel wall beam, and there are also doors and windows installed on the wallboard. At this time, punch holes on the wallboard according to the outline dimensions of the doors and windows. After installing the door and window frames, seal the doors and windows with sealant. When installing doors and windows outside the door frame, first install packaging tape around the doors and windows, and press the packaging tape tightly.

此外要知道，在出廠時廠家贈與出廠合格證和產品質量證明書，在證書上注明產品標準號、鋼板號、鍍鋅數量、表面結構、表面質量、規格、尺寸、形狀精度等詳細參數。針對這種材料，您還有什么不明白的地方可以隨時來我們網站http://szgdbearing.com進行咨詢！

In addition, the manufacturer shall present the factory certificate and product quality certificate when leaving the factory, and indicate the product standard number, steel plate number, quantity of galvanizing, surface structure, surface quality, specification, size, shape accuracy and other detailed parameters on the certificate. For this material, you can come to our website at any time if you don't understand anything http://szgdbearing.com Consult!
